ARCCAPTAIN MIG200 - Multi-Function Digital Operation Panel

10
9.1 Large Digital LED Operation Panel
Detailed description for operation panel functions：
1
VRD, input voltage
VRD LED
110V LED
220V LED
2
Parameter setting and
display area for spot
welding time,
parameter group
storage, voltage and
so on
+
Parameter switch button
Spot welding time LED
Parameter group storage LED
Voltage parameter LED
Parameter LED display
3
Parameter setting and
display area for wire
feed speed and current
Wire feed speed LED
Current parameter LED
Parameter LED display
