Operation
1) After being installed according to the above method, and the power switch on the rear panel being
switched on, the machine is started with digital display on and the fan working.
2) Select “TIG” as the welding mode.
3) According to workpiece thickness, select welding current by adjusting “current adjusting
knob” and ammeter displays this set value. Press torch trigger to start welding.
Arc starting method: As this machine adopts touch start TIG, operator can start normal
welding by slightly raising the torch when there is current after the tungsten is touching the
workpiece.
10.7 Installation and Operation for 2lb(1kg) /11lb(5kg) Roller
Installation of 11lb(5kg) Roller
1) Unscrew the top cover.
2) Install 11lb(5kg) wire on the roller.
3) Tighten the top cover.
