Installation Guideline of Monobloc Unit
Instruction to installation
(1) Installation of the unit must be in accordance with national and local safety codes.
(2) Installation quality will directly affect the normal use of the air conditioner unit. The user is prohibited from
installation. Please contact your dealer after buying this machine. Professional installation workers will provide
installation and test services according to installation manual.
(3) Do not connect to power until all installation work is completed.
Installation of monobloc unit
Selection of installation location of monobloc unit
(1) Monobloc unit must be installed on a firm and solid support.
(2) Avoid placing the monobloc unit under window or between two constructions, hence to prevent normal
operating noise from entering the room.
(3) Air flow at inlet and outlet shall not be blocked.
(4) Install at a well-ventilated place, so that the machine can absorb and discharge sufficient air.
(5) Do not install at a place where flammable or explosive goods exist or a place subject to severe dust,
salty fog and polluted air.
Outline dimension of monobloc unit
AG4HP061PH
