Argo AG4HP061PH - Unit Disassembly Procedures; Exterior Panel and Grille Removal

Air-to-water Heat Pump
54
Disassembly of the unit
Note: firstly please cut off the power supply and discharge refrigerant out of the unit.
Operation Procedure
Illustration
AG4HP061PH;
Remove the fixing bolts, top cover, front panel and right
panel.
Remove the fixing bolts, real panel, connector panel,
support (upright column).
Remove the fixing bolts and outer guard.
Remove the fixing bolts and cover of the electric box.
