Argo AG4HP061PH - Motor Support and Condenser Removal

Air-to-water Heat Pump
60
Note: firstly please cut off the power supply and discharge refrigerant out of the unit.
Operation Procedure
Illustration
AG4HP081PH; AG4HP101PH; AG4HP121PH; AG4HP141PH; AG4HP161PH; AG4HP103PH; AG4HP123PH;
AG4HP143PH; AG4HP163PH
Remove the fixing bolts at the motor and fitting nuts at the
motor support, and then remove the motor and the motor
support.
Fig.13
Seperate the condenser from the base by removing fixing
bolts at them.
Fig.14
