6.9 Camera Function Button Set-up
The following camera functions can be assigned to either of the two function buttons.
Functions can be activated by either a short press (less than one second), or a long press
(three seconds).
• Zoom
• Cycle through selected Application Modes (Fire, Overhaul, Size Up, Inspection,
White Hot, Missing Persons or Black Hot (-C variant only)
• Image Freeze
• Image Capture
• Video Record
• Image Playback
• Video Playback
• Laser Pointer*
• Heat Seeker / Cold Seeker*
*Mi-TIC S only
To assign functions to buttons, select the desired combinations and then click the ‘Save
Changes’ button. Eject the camera from the charger dock. Do not switch the camera off
and back on again. The new settings will be enabled.
