4.2 Battery Life Indicator
With a new, fully charged battery, the battery indicator will
show full with a solid green bar.
The battery indicator represents the normal run time of the
battery, 2 hours for the standard battery and 5 hours for the
optional large battery (ARG_MI_BLPL).
When the battery symbol turns orange, there is
approximately half of the battery life remaining.
When the battery symbol turns red, there is approximately a
quarter of battery life remaining.
When the battery symbol starts to flash, the time remaining
will typically be 10 - 15 minutes.
4.3 Argus
®
Mi-TIC Charger Station Fixed / Vehicle Installation
The Argus
®
Mi-TIC Charger Station can be mounted on any surface either horizontal or
vertically using the universal mounting plate and mounting screws supplied. Note: fixings
for attaching the mounting plate to the surface are NOT supplied.
Up to six (6) charger stations can be powered in a “daisy chain” configuration.
4.3.1 Horizontal Mounting
• Charger Station
• Universal Mounting Plate
• 3 mm hex key
• M4 x 30 mounting screws (2)
• AWG 18 gauge wire (Red and black) (not supplied)
• Small flat bladed screwdriver (not supplied)
• Large flat bladed screwdriver (not supplied)
