24 Quick Start Guide: CloudVision Appliance
Appendix D: Back Panel Features and Indicators
9 USB connector Allow you to connect USB devices to the system. The port is USB
3.0-compliant.
10 System identification button The identification buttons on the front and back panels can be
used to locate a particular system within a rack. When one of
these buttons is pressed, the system status indicator on the back
flashes until one of the buttons is pressed again.
Press to toggle the system ID on and off. If the system stops
responding during POST, press and hold the system ID button for
more than five seconds to enter BIOS progress mode.
To reset the iDRAC (if not disabled in F2 iDRAC setup) press and
hold the button for more than 15 seconds.
11 System identification connector Connects the optional system status indicator assembly through
the optional cable management arm.
12 Ethernet connector 3 Integrated 10/100/1000 Mbps NIC connector.
13 Ethernet connector 4 Integrated 10/100/1000 Mbps NIC connector
14 Power supply (PSU1 and PSU2) Up to two 550 W redundant AC power supplies.
Table D-1 Back-panel features and indicators (Continued)
Indicator, Button, or Connector Description
