Arista MicroBox-7824B-E01 - Network Connection

25
Mouse
Keyboard
Figure 2
MicroBox-7824B-E01
PS2 keyboard jack
PS2 mouse jack
Modem
Connecting to network
• Connect one end of the RJ45 LAN cable to the LAN port of the MicroBox-7824B E-Series
computer. Connect the other end of the RJ45 LAN cable to the LAN port of a modem.
LAN port
LAN port
RJ45 LAN cable(not supplied)
MicroBox-7824B-E01
