Arista MicroBox-7824B-E01 - Product Specifications

6
Product specications
System
CPU Intel 1.9GHz E3845 Quad Core Atom Processor
Chipset Intel E3845 chipset
Memory Up to 8GB, DDR3 SO-DIMM (1333MHz)
Video interface VGA, HDMI
Resolution Up to 1920 x 1080
Storage option SATA DOM, 2.5" HDD, 2.5" SSD, CFast Card
Compactash N/A
GPIO 8-bit GPIO
BIOS American megatrend
Connectors
Video connector 1 x VGA, 1 x HDMI
CFast Card 1 x CFast Card connector
USB port 3 x USB2.0 port, 1 x USB3.0 port
Serial port 4 x RS-232/422/485 BIOS Selectable (MicroBox-
7824B-E01)
1 x RS-232/422/485 BIOS Selectable (MicroBox-
7824B-E02)
GPIO 1 x GPIO port (for MicroBox-7824B-E01)
LAN 2 x Gigabit
Keyboard/Mouse 1x PS2 keyboard, 1x PS2 mouse
Power 1x DC-IN power, 1 x Battery power input(for MicroBox-
7824B-E01)
Operating system
OS Support Windows 7 & up
Physical information
Mounting Wall mounting, DIN-Rail mounting
Physical dimension MicroBox-7824B-E01
:
8.84 X 3.47 X 5.53 inch/ 224.4 X 88.1 X 140.5 mm (L X H X D)
MicroBox-7824B-E02
:
7.71 X 2.50 X 4.59 inch/ 195.8 X 63.5 X 116.5 mm (L X H X D)
Net weight
MicroBox-7824B-E01 : 2.3kg, MicroBox-7824B-E02 : 2.0kg
Mechnical information
Power requirement ( Max ) 24VDC/0.7A (DIN-Rail power supply)
Power consumption ( Max ) 17W
Recommended power supply 24W
Heat dissipation 58 BTU/hr
Operation temperature 0~50
O
C [32~122F]
Storage temperature -20~60
O
C [-4~140F]
Relative humidity 20~90% RH [no condensation]
