Arista MicroBox-7824B-E01 - Physical Dimensions

12
The diagrams below show the physical dimensions of the MicroBox-7824B E -Series
fanless industrial microbox computer.
Top View
Physical dimension
MicroBox-7824B-E01
L(Overall length) H(Overall height) D(Overall width) Weight
8.84”/224.4mm 3.47”/88.1mm 5.53”/140.5 mm 5.1 lb/2.3 kg
108.0 mm
4.25"
140.5 mm
5.53"
224.4 mm
8.84"
212.6 mm
8.37"
Front View
201.4 mm
7.93"
88.1 mm
3.47"
MicroBox-7824-E01
