OVERVIEW
This device is a centralized control unit for thermal solar panels. Supplied with 5 outputs (Load Relays + Alarm Relays) and 4
+nputs (2roDes) it is aDle to manaIe a system conſIuration that can De selected amonI 2 common types of layouts. 9hen a
speciſc installation is selected the control unit automatically manaIes the outputs and inputs used to control the valves the
pumps the inteIrative sources and the proDes used in the type of installation selected.
/oreover on the DacMlit L%& display it is possiDle to visualize the hydraulic diaIram of the installation set up the state of the
outputs the proDes as well as several other data and informations.
The power unit permits to reset the factory-set default data; for further information see the parameter P11 ‘UNIT’.
DESCRIPTION OF THE KEYS
MENU KEY CANCEL KEY MANUAL KEY CONFIRMATION KEY
SELECTION KEYS
RESET KEY
