14
Fig. 2.13
2.9.2 FITTING THE 5” FLUE
(Ø 80 / 125 HORIZONTAL/VERTICAL)
SEE PAGE 19 FOR MAX AND
MIN
FLUE
RUNS
CONTENTS:
HORIZONTAL KIT - 3318095
3X SILICONE O-RINGS (60mm, 80mm & 125mm)
1X 90
O
ELBOW (HORIZONTAL ONLY)
1
X ADAPTOR (60/100 - 80/125MM)
1X HORIZONTAL FLUE PIPE (INCLUDING TERMINAL)
(80/125mm)
2X WALL SEALS (INTERNAL & EXTERNAL)
2
X FLUE CLAMPS
2X SEALS
4X SCREWS
VERTICAL KIT - 3318080 (BLACK) / 3318081 (RED)
1X VERTICAL FLUE PIPE (INCL.TERMINAL) (80/125MM)
1X ADAPTOR (60/100 - 80/125)
1X SILICONE O-RING (60MM)
Should the flue require extending, the flue connections are
push fit, however, one flue bracket should be used to
secure each metre of flue.
Once the boiler has been positioned on the w
all, it is
necessary to insert the
Ø80/125 adaptor (FIG. 2.14)
raised horizontal and vertical flue runs into the boiler flue
sock
et (not supplied with flue kit -
P
ar
t No 3318095
).
Push the adaptor onto the boilers flue connection, g
rease
the seals then add e
xtensions or elbo
ws as required,
secure the adaptor, using the clamp and screws provided.
T
o fit e
xtensions or elbo
ws it is first necessar
y to ensure
that the lip seal is fitted correctly into the inner flue, once
verified, it is simply necessary to push them together, no
Screws
Clamp
Seal
Fig. 2.14
Once cut to the required length, ensure that the flue is
f
ree from burrs and reassemble the flue. If fitting the
flue from inside of the building attach the grey outer
w
all seal to the flue terminal and push the flue through
the hole, once the wall seal has passed through the
hole, pull the flue back into the elbow (ensuring that the
flue seal is not dislodged) until the external wall seal is
f
lush with the wall, and that the flue is securely located
i
nto the elbow, finally secure the flue to the elbow with
the clamp provided. Alternatively, the flue can be
installed from outside of the building, the grey outer
seal being fitted last.
