Ariston microGENUS HE 28 MFFI Installation And Servicing Instructions

28
1
2
3
4
5
6
7
8
9
10
11
AB C D E
12 13 14 15 16
17
18
20
19
21
22
23
24
LEGEND:
1. Fan
2. Heat Exchanger
3. Ov
erheat Thermostat
4.
Centr
al Heating Flo
w NTC
5. Burner
6. Detection Electrode
7.
Ignition Electrodes
8.
Div
erter V
alve
9. Low Water Pressure Switch
10.
Dr
ain Valve
11. Domestic Hot W
ater
T
emper
ature NTC
12. Secondary Heat Exchanger
13. Gas Valve
14.
D
.H.W
.
Flow Switch
15. D.H.W. Inlet Filter
16. Automatic By-pass
17. Saf
ety Valve
18. Pressure Gauge
19. Circulation Pump with Automatic Air Release Valve
20. Condensate Trap
21.
Expansion
V
essel
22. Condensate Sensor
23. Latent Heat Collector
24.
Air Pressure Switch
2.18 WATER CIRCUIT DIAGRAM
FI
G
. 2.34
SI016C
A.
Central Heating Flow
B. Domestic Hot Water Outlet
C
. Gas Inlet
D. Domestic Cold Water Inlet
E. Central Heating Return
