56
6.5.10 Removing the D.H.W. temperature sensor
(
N.T.C.)
1
.
P
ull off the electrical connector and unscrew the
sensor probe using a suitable spanner (FIG. 6.78).
6.5.11 Removing the diverter valve actuator
1. Unplug the electrical connector “C3” (FIG. 6.79);
2. Release the retaining clip “C4” and remove the diverter
valve actuator
6.5.9 Removing the C.H. temperature sensor (N.T.C.)
1. Pull off the electrical connector and remove the sensor
p
robe using a suitable spanner (F
IG.
6.76-6.77).
FI
G
. 6.76
FIG. 6.77
FI
G
. 6.78
FIG. 6.79
C3
C4
