Ariston microGENUS HE 28 MFFI

46
1. Disconnect the electrical connections “L” and silicone
pipes “M” from their connection points (F
IG. 6.20);
2. Remove screws “N” on the top of the sealed chamber
(FIG. 6.21);
3. Lift out the air pressure switch;
4. Unscrew the two screws “O” to remove the switch from
the plate (
F
IG.
6.22 - 6.23
)
;
5. Reassemble in reverse order.
6.3.5 Removing the air pressure switch
FIG.
6.18
FIG. 6.19
FIG. 6.20
M
L
FIG.
6.21
FIG. 6.22
FIG. 6.23
N
O
