Ariston NIMBUS PLUS S NET User Manual

54 / GB
6
8
9
10
1
2
4 5
14
16
7
15
13
12
11
3
1. Circulator
2. Manometer
3. Discharge valves
4. Temperature sensor
(return from the installation) heating/cooling
5. Pressure switch
6. TR Sensor (Temperature Refrigerant)
7. Safety valve 3 bar
8. Condenser assembly
9. Expansion vessel
10. LWT Sensor (Leaving Water Temperature)
11. Automatic air purge
12. Flow meter
13. Heating back-up resistance
14. Safety thermostat (manual switch)
15. Safety thermostat (automatic switch)
16. Temperature sensor (ow to the installation)
heating/cooling
INTERNAL UNIT
Weights and dimensions (mm)
Overall view
A. Hot/cold water ow to the installation G 1” M
B. Cold/Hot water return from the installation G 1” M
C. Gas connection from the external unit 5/8” M
D. Gas connection to the external unit 3/8” M
INTERNAL UNIT
Weight
WH 40 50 S 36
WH 70 S 37
WH 90 110 S 40
52
124
196
268
370
439
138
152
314
58
81
701
728
27
600
A B
C D
