Arkel ADrive Size-B - Braking Resistor Dimensions

ARKEL Elektrik Elektronik Ltd. Şti. www.arkel.com.tr
08.2012
ADrive
14
9.1. Dimensions of Braking Resistors
9.1.1. Braking Resistor Type-A (7.5 HP, 10 HP, 15 HP)
9.1.2. Braking Resistor Type-B (20 HP, 30 HP)
9.1.3. Braking Resistor Type-C (50 HP)
225 mm
20 mm
155 mm
305 mm
180 mm
325 mm
20 mm
115 mm
450 mm
320 mm
250 mm
20 mm
