ARKEL Elektrik Elektronik Ltd. Şti. www.arkel.com.tr
08.2012
ADrive
4
1. INTRODUCTION
ADrive is a high performance motor driver designed for elevators.
Can be used with asynchronous (open loop/closed loop) and synchronous lift motors.
Provides an evacuation operation by driving the motor with back-up power (60-120V battery or
1-phase 220V UPS).
Provides a static auto-tuning for synchronous motors (without rotating the motor).
It supports many different types of absolute (EnDat, SSI and SinCos) and incremental (HTL,
TTL) encoder.
The functions of ADrive are improved to get the best performance especially at start-up and stop.
Start-up and stop accuracy does not change with full load or empty car (for applications with
encoder).
Thanks to vector control, it has the full control of motor from zero speed to maximum speed and
can achieve 200% start-up torque.
For short travel distances the travel curve is automatically readjusted and boring travels at low
speed for short levels are impeded.
The parameter units are convenient for elevators (m, cm, m/s etc.).
The mechanical fan noise and electrical switching noise are minimized, by this no disturbing
noises for residences close to machine rooms are produced.
2. EMC CONFORMITY
This product is in conformity with:
- EN 61000-6-2 Generic standards immunity for industrial environments,
- EN 61000-6-4 Generic standards emission for industrial environments,
- EN 55011 Limits and methods of measurement of radio disturbance characteristics of
industrial, scientific and medical (ISM) radio-frequency equipment and
- EN 61000-3-12 Limits for harmonic currents produced by equipment connected to public
low-voltage systems with input current 16 A and 75 A per phase
with the following installation conditions:
● Installing an AC line reactor to the drive power supply input.
● Installing an EMI filter to the drive power supply input.
● Installing a RFI filter to the drive motor output.
● Using shielded cables for motor, brake resistor and encoder connections outside the
device.
