2-MOTOR SETUP
2.0 – Motor type
2.1 – Nominal speed
2.2 – Motor RPM at nominal speed
2.3 – Incremental encoder resolution
2.4 – Line voltage.
2.5 – Motor nominal voltage
2.6 – Motor nominal current
2.7 – Motor nominal frequency
2.8 – Motor power factor (COS Q)
2.9 – Rotor slip
2.10 – No load motor current (%)
2.11 – Rotor time constant
2.12 – Middle frequency
2.13 – Middle frequency voltage
2.14 – Minimum frequency
2.15 – Minimum frequency voltage
2.16 – Thermal mod
2.17 – Motor direction
2.18 – Encoder direction
2.19 – Number of poles
2.20 – Encoder offset
2.21 – Absolute encoder type
Motor setup affects the driver’s performance directly so these values must be
adjusted carefully in accordance with the information below.
