11. AC line reactor (Line choke)
A 3-phase AC line reactor must be used to comply with the harmonic current limits required by
the EN 61000-3-12 standard.
Note: A DC reactor is integrated inside all ADrive models.
Selection of AC line reactor (380V, 50Hz)
ADrive size Continuous
current (A)
Max. peak
current (A)
Inductance (mH)
kW HP %3 impedance %5 impedance
5.5 7.5 >= 14 >= 28 1.6 2.7
7.5 10 >= 17 >= 34 1.3 2.2
11 15 >= 26 >= 52 0.9 1.5
15 20 >= 35 >= 70 0.7 1.2
22 30 >= 50 >= 100 0.5 0.9
37 50 >= 75 >= 140 0.3 0.5
Note: It is recommended to use AC line reactors with impedance values 3% (Z%) for standard
applications. The impedance value %Z is also the voltage value that drops across the AC line
reactor (for example: 5% voltage drops across the AC line reactor with impedance value 5%).
5% reactor would be a better choice for reducing the harmonic currents with a balanced mains
supply (less than 5% voltage imbalance between phases).
It is suggested that a 3-phase AC line reactor be installed on the supply line also to obtain the
following benefits:
- limiting the input current peaks on the input circuit of the inverter
- increasing the duration of line capacitors inside the inverter
- increasing power factor, thus reducing line current
