ARKEL Elektrik Elektronik Ltd. Şti. www.arkel.com.tr
08.2012
ADrive
7
5. TECHNICAL SPECIFICATIONS
Type
Size-B Size-C Size-D
Model 4B055 4B075 4B110 4C150 4C220 4D370
Motor Power (HP) 5.5 kW
7.5HP
7.5 kW
10HP
11 kW
15HP
15 kW
20HP
22 kW
30HP
37 kW
50HP
Nominal Output Current (Inom) 14 A 17 A 26 A 35 A 50 A 75 A
Maximum Output Current (< 6 s) 28 A 34 A 52 A 70 A 100 A 140 A
Input Power Factor (Cos Q) > 0.97
Input Voltage (V)
AC 3 Faz, 340-420V, 50/60 Hz
%5
Output Voltage (V) AC 3 Faz, 0-400V, 0-100Hz
Control Type ● Closed Loop Vector Control
● Open Loop V/F (for asynchronous drive)
Digital output frequency
resolution
0,004 Hz
PWM modulation method Space vector modulation
Output wave shape Sinus
Carrier frequency 10Khz
Encoder type Incremental HTL or TTL , 500 – 4096 pulse incremental encoder
Absolute EnDat, SSI and SinCos absolute encoders
Encoder simulation outputs ● Absolute encoder simulation outputs
● Incremental encoder simulation outputs
Protection Built-in DC REACTOR (Dc choke)
Input-output isolation All isolated control inputs and outputs
Cooling 4 low noise fans
Serial communication ports ● RS-485 port for communication with lift controller
● CANbus port for communication with ENCABIT-Plus
Evacuation operation with
back-up power
Control circuit supply With external 24Vdc feeding
Power circuit supply ● 60-120VDC battery
● 1-phase 230VAC UPS
Special functions ● Motor and brake resistor temperature monitoring
● Brake release monitoring
● Manual evacuation mode activating input & special
evacuation screen
● Unintended car movement (UCM) simulation mode
Fault history Last 256 errors
Onboard user interface 2x16 character LC-Display & 5-key keypad
Remote operation With ADrive Remote Keypad
PC connection RS-232 port (for ADrive-Win Simulator & Monitor
software)
Saving and transferring
parameters
With Data Key
User interface 2x16 character LC-Display, 5-key keypad
Firmware upgrading Firmware version V8.00 and later
