23. ADrive PARAMETER LIST
ADrive MENU
USER
SETTINGS
FACTORY DEFAULTS
Induction
Synchronous
5,5 kW
7,5 kW
11kW
15kW
22kW
37kW
5,5 kW
7,5 kW
11kW
15kW
22kW
37kW
TRAVEL CURVE
1.1
High speed (V3)
1,0 m/s
1.2
Middle speed (V2)
0,5 m/s
1.3
Inspection speed (V1)
0,2 m/s
1.4
Low speed (V0)
0,13 m/s
1.5
Acceleration (Pa)
0,4 m/s
2
1.6
Acceleration begin soften (S1)
0,3 m/s
3
1.7
Acceleration end soften (S2)
0,4 m/s
3
1.8
Slowing distance (X_SLW)
165 cm
1.9
Stopping distance (X_STP)
8,0 cm
1.10
Stopping type
Stop with distance
1.11
Deceleration (Na)
0,7 m/s
2
1.12
Deceleration begin soften (S3)
0,8 m/s
3
1.13
Deceleration end soften (S4)
0,8 m/s
3
1.14
Mechanical brake on delay (MB_ON)
0,8 s
1.15
Mechanical brake off delay (MB_OFF)
0,5 s
1.16
Initializing jerk (As)
0,03 m/s2
1.17
Initializing speed (Vs)
0,0 m/s
1.18
Initializing time (Ts)
0,0 s
MOTOR SETUP
2.0
Motor type
Induction
Synchronous
2.1
Nominal speed
1,0 m/s
2.2
Motor RPM at nominal speed
60
2.3
Incremental encoder resolution
1024
-
2.4
Line voltage
380 V
2.5
Motor nominal voltage
380 V
2.6
Motor nominal current
9,0 A
14,0 A
19,0 A
25,0 A
35,0 A
50,0 A
9,0 A
14,0 A
19,0 A
25,0 A
35,0 A
50,0 A
2.7
Motor nominal frequency
50 Hz
-
2.8
Motor power factor (COS Q)
0,8
2.9
Rotor slip
2,0 Hz
1,7 Hz
1,5 Hz
1,2 Hz
1 Hz
0,7 Hz
-
2.10
No load motor current (%)
%40
-
2.11
Rotor time constant
150 ms
150 ms
250 ms
300 ms
400 ms
500 ms
-
2.12
Middle frequency
4,0 Hz
-
2.13
Middle frequency voltage
40 V
-
2.14
Minimum frequency
0,5 Hz
-
2.15
Minimum frequency voltage
22 V
-
2.16
Thermal mod
%100
2.17
Motor direction
Not inverted
2.18
Encoder direction
Not inverted
2.19
The number of poles
-
16
2.20
Encoder offset
-
0,0'
2.21
Absolute encoder type
-
SC.-ENDAT 2048
CONTROLLER SETUP
3.1
KP0
900
3.2
KI0
12
3.3
KP1
750
3.4
KI1
10
3.5
Anti-Rollback position controller
Enabled
3.6
Anti-Rollback position controller Kp gain
60
3.7
Anti-Rollback position controller Kd gain
30
3.9
Encoder filter
3
3.10
Dynamic filter
Enabled
CONTROL TYPE
6.1
Control type
Closed loop
PASSWORD
10.1
Password
0000
ADVANCED SETTINGS
11.1
Switching F
10 Khz
11.2
Current controller KI gain
75
11.3
Current controller KP gain
4000
11.4
PIN programmable input function
Error reset
11.5
Flim frequency
50 Hz
11.6
Brake release monitoring
Disabled
11.7
PTC temperature monitoring
Disabled
11.8
Over-gain detection function
Enabled
11.10
Trip Imax
20 A
29 A
45 A
65 A
95 A
99 A
20 A
29 A
45 A
65 A
95 A
99 A
11.11
Trip ImaxT
5,0 s
11.12
T_Current gain
%100
11.13
Cur. Limit
28,2 A
35,3 A
53,0 A
70,0 A
101,1 A
140 A
28,2 A
35,3 A
53,0 A
70,0 A
101,1 A
140 A
BATTERY OPERATION
12.1
Battery voltage
220-UPS
12.2
Battery direction
Easiest direction
12.3
Battery speed
0,1 m/s
12.4
UPS power
20,0 kW
