6. FUSE, CONTACTOR and CABLE CROSS-SECTION
*1: Evacuation in the lower load direction
*2: Evacuation in the command direction given by the lift controller
Fuses (Ampere)
7.5HP
5.5kW
10HP
7.5kW
15HP
11kW
20HP
15kW
30HP
22kW
50HP
37kW
Mains fuse (Type B)
20
25
32
50
63
100
Battery fuse (Type C)
1.5 x battery capacity (Ah)
UPS fuse (Type B)
1.5 x (UPS power (W) / 220V)
Contactors (Ampere, category AC-
3)
7.5HP
5.5kW
10HP
7.5kW
15HP
11kW
20HP
15kW
30HP
22kW
50HP
37kW
Motor contactors (KPA, KPB)
>= 12
>=18
>=25
>=32
>=50
>= 80
Mains supply contactor (KSAK)
>= 9
>=12
>=18
>=25
>=40
>= 65
Back-up power supply contactor
(KKAK)
>= 9
>=9
>=12
>=18
>=32
>= 50
Cable cross-section (mm²)
7.5HP
5.5kW
10HP
7.5kW
15HP
11kW
20HP
15kW
30HP
22kW
50HP
37kW
Mains supply cables
>= 2.5
>= 4
>= 6
>= 10
>= 16
Motor connection cables
>= 2.5
>= 4
>= 6
>= 10
>= 16
Brake resistor cables
>= 1
>= 1.5
>= 2.5
>= 4
Battery power connections
>= 1.5
>= 2.5
>= 4
>= 6
>= 10
UPS power connections
*1
>= 1
>= 1.5
>= 2.5
>= 4
>= 6
*2
>= 1.5
>= 2.5
>= 4
>= 6
>= 10
Control signal cables
>= 0.5
