Array electronic FAB Series User Manual

FAB I
ntelligent
C
ontrollerr
4. Select and setup the third function block
Press
to return to the Function Block Selection List Frame and select the
third function block.
Move > to the position of OR function block and press
. Now you can set
the parameters for the third function block. The following will be displayed on
the LCD panel:
Press to enter the rst input parameter setting status. Select parameter M
with
, and set its parameter value with or . When M01 ap-
pears, press
and the rst parameter will be set to M1. The following will be
on the LCD panel:
Fig. 4.41
Press to move the cursor to the second input parameter. Press key,
then the second input parameter can be set. After selecting X with
or
, the mentioned input is set to be X. The following will be displayed on the LCD
panel:
Fig. 4.42
Move the cursor to the third input Pin and press . After selecting M in the
parameter list, press
and set this input to be M2 with and .
B03
62
Fig. 4.40
M01
M01
X
B03
B03
