6-42 CHP Max™ Headend Optics Platform Chassis, Controllers and Power Supplies 1508685 Rev D
Power Supply and Fan Module Slots
CHP Controller Module Slots
Table 6.8 Slot-Hardware-MIB Associations for Power Supply (slots 11 and 12) and Fan Bay (slot
13)
CHP Shelf
Virtual Slot
index
Possible
Hardware
Types
Supported IETF
Objects
Supported HMS
Objects
Supported ARRIS
Objects
Slots
11 (upper) or
12 (lower)
DC Power
Supply / AC
Power Supply
entPhysicalTable heCommonTable
hePsMIBObjects
hePsUnitTable
hePsOutputTable
propertyTable
discretePropertyTab
le
chpCommonMIB
chpSlotConfigTabl
e
chpSlotStatusTable
chpPsMIB
psStatusTable
Slot 13 Fans entPhysicalTable heCommonTable
heFanMIBObjects
heFanUnitTable
heFanStatusTable
propertyTable
discretePropertyTab
le
chpCommonMIB
chpSlotConfigTabl
e
chpSlotStatusTable
Table 6.9 Slot-Hardware-MIB Associations for Controller Module Slots 14 and 15
CHP
Shelf
Virtual
Slot
index
Possible
Hardware
Types
Supported IETF
Objects
Supported HMS
Objects
Supported ARRIS
Objects
Slot 14 CMM/CMM-1 entphysicalTable heCommonTable
propertyTable
discretePropertyTable
chpCommonMIB
chpSlotConfigTable
chpSlotStatusTable
chpCMMControllerMI
B
cmmParamTable
cmmControltable
cmmStatusTable
