Arris CHP Max5000 - Optical Amplifier

B-26 CHP Max™ Headend Optics Platform Chassis, Controllers and Power Supplies 1508685 Rev D
Optical Amplifier
1.3.6.1.4.1.2907.20.2.1.5.1
.2.1.2.50005.1.1
.iso.org.dod.internet.private.enterp
rises.ccor-reg-ident.ccorHeadend.c
corHeadendMIB.chpMax5000MIB.c
hpTxMIB.txMIBObjects.txInputTabl
e.txInputEntry.txInputRFLevel.5000
5.1
Transmitter RF Level Alarm
1.3.6.1.4.1.5591.1.11.1.1.1
.1.3.1.8.50005.1.1
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heOptics.heOpticalTrans
mitterGroup.heOpticalTransmitter
MIB.heOpTxMIBObjects.heOpTxLas
erTable.heOpTxLaserEntry.heOpTx
LaserOutputStatus.50005.1
Transmitter Laser On/Off Status
Table B.11 EDFA and EDFA-CG Module
heCommonLogOID MIB heCommonLogText
1.3.6.1.4.1.5591.1.11.1.3.1
.1.2.1.2.50001.1
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heOptics.heOpticalAmplifi
erGroup.heOpticalAmplifierMIB.he
OpAmpMIBObjects.heOptAmpInpu
tTable.heOpAmpInputEntry.heOpA
mpInputPower
Amplifier Optical Input Power
Alarm
1.3.6.1.4.1.5591.1.11.1.3.1
.1.3.1.2.50001.1
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heOptics.heOpticalAmplifi
erGroup.heOpticalAmplifierMIB.he
OpAmpMIBObjects.heOpAmpLaser
Table.heOpAmpLaserEntry.heOpA
mpLaserTemp
Amplifier Pump 1 Laser
Temperature Alarm
Amplifier Pump 2 Laser
Temperature Alarm
1.3.6.1.4.1.5591.1.11.1.3.1
.1.3.1.3.50001.1
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heOptics.heOpticalAmplifi
erGroup.heOpticalAmplifierMIB.he
OpAmpMIBObjects.heOpAmpLaser
Table.heOpAmpLaserEntry.heOpA
mpLaserBiasCurrent
Amplifier Pump 1 Laser Bias
Current Alarm
Amplifier Pump 2 Laser Bias
Current Alarm
1.3.6.1.4.1.5591.1.11.1.3.1
.1.4.1.3.50001.1
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heOptics.heOpticalAmplifi
erGroup.heOpticalAmplifierMIB.he
OpAmpMIBObjects.heOpAmpOutp
utTable.heOpAmpOutputEntry.heO
pAmpGainPerWavelength
Amplifier Output Optical Gain
Table B.10 RTX-DWDM Module (cont’d)
heCommonLogOID MIB heCommonLogText
