Table A.10 Fan Parameters
Attribute Parameter MIB Object MIB Type
Module
Identification
Hardware Version
ServiceTrackingNumber
entPhysicalHardwareRev
chpSlotStatusModuleServiceNu
m
STANDARD
ENTERPRISE
Monitorable
Parameters
The response shall be in the
following order: Fan 1, 2, 3, 4, 5,
6, 7, 8
heFanStatusCurrent STANDARD
Status Alarm Bytes cmmStatusFanAlarms ENTERPRISE
Fan Current
Threshold
Major Low
Minor Low
Minor High
Major High
analogAlarmLOLO
analogAlarmLO
analogAlarmHI
analogAlarmHIHI
STANDARD
STANDARD
STANDARD
STANDARD
Alarm States Value of AlarmState can be
Major Low, Minor Low, Minor
High, or Major High.
currentAlarmState STANDARD
Alarm Enable
States
AlarmEnable can
enabled/disabled for the
following alarms: Major Low,
Minor Low, Minor High, Major
High.
alarmEnable STANDARD
Deadbands Deadbands may be set for each
monitorable parameter.
analogAlarmDeadband STANDARD
Firmware
Upgrades
Boot Version
Download Version
entPhysicalFirmwareRev
entPhysicalFirmwareRev
STANDARD
STANDARD
Table A.11 Parameters Common to All Modules
Attribute Parameter MIB Object MIB Type
Slot Down Major chpSlotStatusPhysicalState ENTERPRISE
Slot Empty Major chpSlotStatusPhysicalState ENTERPRISE
Slot
Unknown
Major chpSlotStatusPhysicalState ENTERPRISE
Module
Mismatch
Major chpSlotStatusPhysicalState ENTERPRISE
Internal
Temperature
Major Low
Minor Low
Minor High
Major High
heCommonTemperature ENTERPRISE
