Arris CHP Max5000 User Manual

1508685 Rev D CHP Max Trap Information B-17
1.3.6.1.4.1.5591.1.11.1.2.1
.1.2.1.4.50004.1
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heOptics.heOpticalReceiv
erGroup.heOpticalReceiverMIB.he
OpRxMIBObjects.heOpRxOutputTa
ble.heOpRxOutputEntry.heOptRxO
utput.50004.1
Rx RF Output Power Alarm
1.3.6.1.4.1.5591.1.11.2.1.1
.1.1.1.1.2.50008
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heBaseIdent.heCommon.
heCommonMib.heCommonObjects
.heCommonParams.heCommonTa
ble.heCommonEntry.heCommonTe
mperature.50008
Receiver Internal Temperature
Alarm
1.3.6.1.4.1.2907.20.2.1.1.1
.2.2.1.1.50006.2
.iso.org.dod.internet.private.enterp
rises.ccor-reg-ident.ccorHeadend.c
corHeadendMIB.chpMax5000MIB.c
hpCommonMIB.chpCommonMIBO
bjects.chpMaxSlots.chpSlotStatusT
able.chpSlotStatusEntry.chpSlotStat
usPhysicalState.50006
Module Communication Status
Down
Module Removed
Module Communication
1.3.6.1.4.1.2907.20.2.1.7.1
.2.1.2.50006.1.1
.iso.org.dod.internet.private.enterp
rises.ccor-reg-ident.ccorHeadend.c
corHeadendMIB.chpMax5000MIB.c
hpRxMIB.rxMIBObjects.rxChCtlTabl
e.rxChCtlEntry.rxChCtlRfStatus.500
06.1
The selected Rx output was set to
enable.
The selected Rx output was set to
low.
The selected Rx output was set to
off.
1.3.6.1.4.1.5591.1.11.1.2.1
.1.1.1.4.50006.1.2
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heOptics.heOpticalReceiv
erGroup.heOpticalReceiverMIB.he
OpRxMIBObjects.heOpRxInputTabl
e.heOpRxInputEntry.heOpRxInputS
tatus.50006.1
The selected Rx output was set to
enable.
The selected Rx output was set to
low.
The selected Rx output was set to
off.
Table B.4 GFRX Module
heCommonLogOID MIB heCommonLogText
1.3.6.1.4.1.5591.1.11.1.2.1
.1.1.1.2.50008.1
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heOptics.heOpticalReceiv
erGroup.heOpticalReceiverMIB.he
OpRxMIBObjects.heOpRxInputTabl
e.heOpRxInputEntry.heOpRxInputP
ower.50008.1
Rx A Optical Input Power Alarm
Table B.3 FRX Module (cont’d)
heCommonLogOID MIB heCommonLogText
