B-24 CHP Max™ Headend Optics Platform Chassis, Controllers and Power Supplies 1508685 Rev D
Table B.9 XMOD and GMOD Modules
heCommonLogOID MIB heCommonLogText
1.3.6.1.4.1.5591.1.11.1.1.1
.1.3.1.2. 50009.1
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heOptics.heOpticalTrans
mitterGroup.heOpticalTransmitter
MIB.heOpTxMIBObjects.heOpTxLas
erTable.heOpTxLaserEntry.heOpTx
LaserTemp.50009.1
Transmitter Laser Temperature
Alarm
1.3.6.1.4.1.5591.1.11.1.1.1
.1.3.1.3. 50009.1
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heOptics.heOpticalTrans
mitterGroup.heOpticalTransmitter
MIB.heOpTxMIBObjects.heOpTxLas
erTable.heOpTxLaserEntry.heOpTx
LaserBiasCurrent.50009.1
Transmitter Laser Bias Current
Alarm
1.3.6.1.4.1.5591.1.11.1.1.1
.1.3.1.4. 50009.1
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heOptics.heOpticalTrans
mitterGroup.heOpticalTransmitter
MIB.heOpTxMIBObjects.heOpTxLas
erTable.heOpTxLaserEntry.heOpTx
LaserOutputPower.50009.1
Transmitter Optical Power Alarm
1.3.6.1.4.1.5591.1.11.2.1.1
.1.1.1.1.2.50009
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heBaseIdent.heCommon.
heCommonMib.heCommonObjects
.heCommonParams.heCommonTa
ble.heCommonEntry.heCommonTe
mperature. 50009
Transmitter Internal Temperature
Alarm
1.3.6.1.4.1.2907.20.2.1.1.1
.2.2.1.1.50009.2
.iso.org.dod.internet.private.enterp
rises.ccor-reg-ident.ccorHeadend.c
corHeadendMIB.chpMax5000MIB.c
hpCommonMIB.chpCommonMIBO
bjects.chpMaxSlots.chpSlotStatusT
able.chpSlotStatusEntry.chpSlotStat
usPhysicalState.50009
Module Communication Status
Down
Module Removed
Module Communication Status
1.3.6.1.4.1.2907.20.2.1.5.1
.2.1.2. 50009.1.1
.iso.org.dod.internet.private.enterp
rises.ccor-reg-ident.ccorHeadend.c
corHeadendMIB.chpMax5000MIB.c
hpTxMIB.txMIBObjects.txInputTabl
e.txInputEntry.txInputRFLevel.5000
9.1
Transmitter RF Level Alarm
1.3.6.1.4.1.5591.1.11.1.1.1
.1.3.1.8.50009.1.1
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heOptics.heOpticalTrans
mitterGroup.heOpticalTransmitter
MIB.heOpTxMIBObjects.heOpTxLas
erTable.heOpTxLaserEntry.heOpTx
LaserOutputStatus.50009.1
Transmitter Laser On/Off Status
