Connecting Your DCX Set-top
Connecting an SDTV — Single Connection for Video/Audio
1. Connect an RF coax cable to the RF OUT connectors on the DCX set-top and Cable/Antenna
IN input connector on the Standard-Definition TV (SDTV).
This video connection method does not support HD video. If you have an HDTV, see Connecting
an HDTV — Single Connection for Video/Audio
Figure 4: Connecting an SDTV — Single Connection for Video/Audio
All-Digital, High-Definition Set-top DCX525 • User Guide 8
© ARRIS Enterprises, Inc. 2015 All rights reserved. 365-095-25821 x.2
