Connecting Your DCX Set-top

Connecting an A/V Receiver, SDTV and VCR/DVD Recorder

1. Connect an HDMI cable to the HDMI output connector on the DCX set-top and the HDMI

input connector on the A/V receiver.

2. Connect a stereo audio cable to the VCR/DVD recorder audio L/R output connectors on the

A/V receiver and the audio L/R input connectors on the VCR/DVD recorder.

3. Connect a stereo audio cable to the audio L/R output connectors on the VCR/DVD recorder

and the VCR audio L/R input connectors on the A/V receiver.

4. Connect a composite video cable to the composite video input connector on the VCR/DVD

recorder and the composite video VCR output connector on the A/V receiver.

5. Connect a composite video cable to the composite video output connector on the VCR/DVD

recorder and the composite video VCR input connector on the A/V receiver.

6. Connect a composite video cable to the composite video input connector on the Standard-

Definition TV (SDTV) and the TV/monitor composite video output on the connector on the

A/V receiver.

Note: These video connection methods do not support HD video. If you have an HDTV, see Connecting

an HDTV — Single Connection for Video/Audio

All-Digital, High-Definition Set-top DCX525 • User Guide 10
