Configuring the User Settings
Table 2: User Settings Menu Field Descriptions
Allows you to specify the style of television connected to the DCX525. The 16:9 option is the
default.
• 16:9 — A widescreen television is connected to the DCX525.
• 4:3 Letterbox — A standard-screen television is connected to the DCX525 and widescreen
programs should be scaled to fit the screen with black bars above and below the picture.
• 4:3 Pan Scan—A standard-screen television is connected to the DCX525 and widescreen
programs should be cropped so the picture fills the entire screen.
Allows you to select the video format of the HDMI output:
• For ALL programs when the 4:3 Override setting is set to either Off or Stretch.
• For ONLY widescreen programs when the 4:3 Override is set to either 480i or 480p.
The 1080i option is the default.
• 1080p60 — High-Definition 1080p60 format (1920 x 1080 pixels with progressive scanning at
60 frames per second). This is only available with HDMI. For component output, 1080p is
down-converted to 480i.
• 1080i — High-Definition 1080i format (1920 x 1080 pixels with interlaced scanning at 30
frames per second).
• 720p — High-Definition 720p format (1280 x 720 pixels with progressive scanning at 60 frames
per second).
• 480p — Enhanced-Definition 480p format (720 x 480 pixels with progressive scanning at 60
frames per second).
• 480i —Standard-Definition 480i format (720 x 480 pixels with interlaced scanning at 30 frames
per second).
• Native — Format that most closely matches the program’s native format according to the list
of compatible formats selected from the Native Mode Settings menu screen.
Note :Not all televisions will support all available video formats. Consult the television’s user manual for
more information on video format compatibility.
The DCX525 can detect when the HDMI connection is in use. If you are not using the HDMI connection
on the DCX525, the Additional HDMI Settings option is disabled and can’t be selected in the menu..
Most new HDTVs are equipped with at least one HDMI input and can support the 1080p60 format. The
DCX525 is designed to provide excellent video quality when converting any program to the 1080p60
video format. If your television supports 1080p60 video input, it is highly recommended to adjust the
HDMI Output setting to the 1080p60 setting.
