Arris Touchstone DG2460 - Patterns: Normal Operation (WAN)

Chapter 6: Using the Data Gateway
Mode Ethernet
(LEDs on rear
panel
connector)
2.4G Wi-Fi / 5G
Wi-Fi
AC Power Green LED On =
Computer with
1Gbps port
connected
Amber LED On
= Computer with
100
Mbps/10Mbps
port connected
Amber/Green
LED Flash =
Computer activity
Both LEDs Off =
Computer not
connected
On = Wi-Fi enabled
Flash = Computer
activity
Off = Wi-Fi disabled
No AC Power Off Off
Firmware
Upgrade
(normal
operation)
(normal operation)
Patterns: Normal Operation (WAN)
The following table shows light patterns during normal operation.
Mode Power US/DS Online
AC Power Good On On = Connected
to the Internet
Flash = Not
connected to the
Internet
On = Internet
available
Off = Internet not
available
No AC Power Off Off Off
Firmware
Upgrade
On Flash On
Release 24 STANDARD 1.1 February 2015 Touchstone DG2460 Data Gateway User Guide 30
