13
English
Introduction
m Loop-through output
Outputs input signal as is from b to f, j. Confirms input
signal, connects to input terminal of other video devices.
Furthermore, for a b VIDEO, c Y/G, d P
B/B, e PR/R input
terminal, when not connected to any output terminal,
terminated with internal 75 ohm. If a cable is connected to
the output terminal, internal terminal automatically opens.
When a cable connected to the output terminal is not
connected to a video device, and when the connected
video device is not terminated with 75 ohm, the signal
level becomes too large and cannot be displayed correctly.
● There will be no output from the S VIDEO terminal when
the power is not switched on.
n SDI input terminal (BNC type)
Connects devices having SDI output terminals.
o SDI output terminal (BNC type)
When the monitor power is on, the signal input to SDI is
output as is. Connects devices having SDI input terminals.
p DVI-D 1/2 input terminal (DVI-D)
Connects devices having DVI-D output.
● DVI-D 1 input terminal only, HDCP is supported.
● Use cables rated for DVI compliance. (May not display due
to cable length and quality.)
q DVI-D 2 output terminal (DVI-D)
When the monitor power is on, the signal input to DVI-D 2
is output. Connects devices having DVI-D input terminals.
r Screw holes for attachments
Screw holes for attaching fixtures that support VESA
mount rating (100 mm (3.9) × 100 mm (3.9)).
● Regarding terminals for c-f, i, perform input setup to
match input signal form. (page 23)
Connect only devices conforming to the
Electrical Appliance and Material Safety
Law or IEC specification to the device
interface
(e.g.)
IEC 60950-1
UL 60950-1
CAN/CSA-C22.2 No. 60950-1
EN 60950-1
IEC 60601-1
ANSI/AAMI ES60601-1:2005
UL 60601-1
CAN/CSA-C22.2 NO. 60601-1-08
EN 60601-1
Connecting to other devices risks an
increase in leakage current. Further, if
connecting the device to medical
equipment as a medical system, make
sure to conform to the medical system
requirements (IEC 60601-1-1 or
EN 60601-1-1).
EJ-MLA26_EN_Arthrex.book Page 13 Wednesday, August 8, 2012 11:58 AM
