Displayable Input Signals
● The input signal above is a displayable input signal when using one monitor (when not connected to output).
✔ : Displayable input signals
*1 If a 640x480@60Hz signal is input and RGB-VIDEO mode is selected, it is recognized as 480/60p.
If a 1920x1080@60Hz signal is input and RGB-VIDEO mode is selected, it is recognized as 1080/60p.
Improper settings may lead to misalignment of display positions.
*2 If a 480/60p signal is input and RGB-PC mode is selected, it is recognized as 640x480@60Hz.
If a 1080/60p signal is input and RGB-PC mode is selected, it is recognized as 1920x1080@60Hz.
Improper settings may lead to misalignment of display positions.
*3 When the resolution of the input signal is different from that of the screen display, change the setting value of the
signal format. (page 24)
*4 A 1920x1080@60Hz signal of DVI-D is recognized as 1080/60p.
● In RGB mode, please input sync on green or composite sync as sync signal. Some PCs cannot display images.
Signal name
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
VIDEO,
SVIDEO
SDI
RGB/
YP
BPR
RGB/YPBPR, HD15
DVI-D 1,
DVI-D 2
(YP
BPR
mode)
(RGB-
VIDEO
mode)
(RGB-PC
mode)
NTSC 15.73 59.94 ✔
PAL 15.63 50.00 ✔
480/60i 15.73 59.94 ✔✔✔✔✔
480/60p 31.47 59.94 ✔✔*2 ✔
576/50i 15.63 50.00 ✔✔✔✔✔
576/50p 31.25 50.00 ✔✔✔✔
720/60p 45.00 60.00 ✔✔✔✔✔
720/50p 37.50 50.00 ✔✔✔✔✔
1080/60i 33.75 60.00 ✔✔✔✔✔
1080/60p 67.50 60.00 ✔✔*2 ✔
1080/50i 28.13 50.00 ✔✔✔✔✔
1080/50p 56.25 50.00 ✔✔✔✔
1080/30p 33.75 30.00 ✔✔✔✔✔
1080/25p 28.13 25.00 ✔✔✔✔✔
1080/24p 27.00 24.00 ✔✔✔✔✔
1080/24PsF 27.00 48.00 ✔✔✔✔
1250/50i 31.25 50.00 ✔✔✔
640x400@70Hz 31.46 70.07 ✔✔
640x480@60Hz 31.47 59.94 *1 ✔✔
640x480@72Hz 37.86 72.81 ✔✔
640x480@75Hz 37.50 75.00 ✔✔
640x480@85Hz 43.27 85.01 ✔✔
800x600@56Hz 35.16 56.25 ✔✔
800x600@60Hz 37.88 60.32 ✔✔✔
800x600@72Hz 48.08 72.19 ✔✔
800x600@75Hz 46.88 75.00 ✔✔
800x600@85Hz 53.67 85.06 ✔✔
1024x768@60Hz 48.36 60.00 ✔*3 ✔*3 ✔
1024x768@70Hz 56.48 70.07 ✔✔
1024x768@75Hz 60.02 75.03 ✔✔
1024x768@85Hz 68.68 85.00 ✔✔
1152x864@75Hz 67.50 75.00 ✔✔
1280x768@60Hz 47.70 60.00 ✔*3 ✔*3 ✔
1280x800@60Hz 49.70 59.81 ✔✔✔
1280x960@60Hz 60.00 60.00 ✔✔✔
1280x1024@60Hz 63.98 60.02 ✔✔✔
1280x1024@75Hz 79.98 75.03 ✔✔
1400x1050@60Hz 65.32 59.98 ✔*3 ✔*3 ✔
1440x900@60Hz 55.94 59.89 ✔✔✔
1680x1050@60Hz 65.29 59.95 ✔*3 ✔*3 ✔
1600x1200@60Hz 75.00 60.00 ✔*3 ✔*3 ✔
1920x1080@60Hz 67.50 60.00 *1 ✔✔*4
1920x1200@60Hz 74.04 59.95 ✔*3 ✔*3 ✔
(4 : 3) (Wide)
1024x768@60Hz, 1600x1200@60Hz, 1400x1050@60Hz 1280x768@60Hz, 1920x1200@60Hz, 1680x1050@60Hz
Setting
