34
Pin Specifications
■ Pin assignment and signal name of RS-232C terminal
■ Pin assignment and signal name of HD15 input terminal (mini D-sub15 pin)
■ Pin assignment and signal name of GPI terminal
■ Pin assignment and signal name of DVI-D terminal
■ Pin assignment and signal name of DC IN terminal
Pin No. Signal name Content
a
CD NC (no connection)
b
TXD Transmission data
c
RXD Reception data
d
DSR Short circuit at pin 6 on the monitor
e
GND GND
f
DTR Short circuit at pin 4 on the monitor
g
CTS Short circuit at pin 8 on the monitor
h
RTS Short circuit at pin 7 on the monitor
i
RI NC (no connection)
Please connect PC with straight RS-232C cable (male-female).
Pin No. Signal name Pin No. Signal name
a
R
i
NC (no connection)
b
G
j
GND
c
B
k
NC (no connection)
d
NC (no connection)
l
SDA
e
GND
m
HD/SYNC
f
GND
n
VD
g
GND
o
SCL
h
GND
Pin No. Signal name
a
GPI1
b
GPI2
c
GPI3
d
GPI4
e
GND
f
GPI5
g
GPI6
h
GPI7
i
GPI8
Pin No. Signal name Pin No. Signal name
a
T.M.D.S. data 2-
m
b
T.M.D.S. data 2+
n
DC 5 V
c
T.M.D.S. data 2 shield
o
GND
dp
Hot plug sense
eq
T.M.D.S. data 0-
f
DDC clock
r
T.M.D.S. data 0+
g
DDC data
s
T.M.D.S. data 0 shield
ht
i
T.M.D.S. data 1-
u
j
T.M.D.S. data 1+
v
T.M.D.S. clock shield
k
T.M.D.S. data 1 shield
w
T.M.D.S. clock+
lx
T.M.D.S. clock-
Pin No. Signal name
a
GND
b
GND
c
DC 24 V
d
DC 24 V
EJ-MLA26_EN_Arthrex.book Page 34 Wednesday, August 8, 2012 11:58 AM
To Next Page
