27
Setting
English
System Configuration
Settings for devices
● System configuration menu
The display location of main menu, “Input Select” menu and
preset menu is set here.
Saves currently set values, and the status for each user is
displayed.
See “PRESET and USER Setting” on page 21 for details.
❑ Selectable Value
USER1-20
Sets whether information about the current input signal and
terminal name is displayed. Information about the resolution at
the PC signal input is also displayed.
Settings for switching on can be set in advance.
● The character strings of “USER1” – “USER20” (USER
NAME) can be changed via the RS-232C port.
Sets the language to be used for display in settings and all
menus.
❑ Selectable Value
English, Deutsch, Français, 日本語, Italiano, Español
Menu Position
❑ Selectable Value
:
Selected screens are displayed in the center of
the panel.
:
Selected screens are displayed in the upper right
corner of the panel.
:
Selected screens are displayed in the lower right
corner of the panel.
:
Selected screens are displayed in the lower left
corner of the panel.
:
Selected screens are displayed in the upper left
corner of the panel.
Data Save
Status Display
❑ Selectable Value
Continue: Information is always displayed.
3Sec: Information displays for 3 seconds. After
3 seconds, information display disappears.
Off: Information not displayed.
USER1
3Sec
Data Save
Status Display
Last
English
Power On Setup
Language
Return
Select
Change
Input Config
Video Config
System Config
Function
Window Config
Remote
Control
Menu Position
Power On Setup
❑ Selectable Value
Last: Last saved state starts.
PRESET1-9: State saved in PRESET is called.
9 types of PRESET are stored in advance in
the monitor as fixed data.
FACTORY: Returns to factory settings.
USER1-20: State stored in USER is called.
It is possible to store 20 types of data in
USER.
Language
EJ-MLA26_EN_Arthrex.book Page 27 Wednesday, August 8, 2012 11:58 AM
