Specifications
■ LCD monitor
■ AC adaptor
Power Source DC 24 V 69 W
LCD Panel 26 inch (16:9 aspect ratio)
Number of pixels 2 073 600 pixels (1920 × 1080)
Viewing angle Horizontal: 178 ° Vertical: 178 °
Video input terminal 1.0 Vp-p (75 )BNC type
Video output terminal 1.0 Vp-p (75 )BNC type
S Video input terminal
Luminance: Chrominance signal separation 4 pin mini DIN
Luminance signal: 1.0 Vp-p (75 ), Chrominance signal: 0.286 Vp-p (75 )
S Video output terminal
Luminance: Chrominance signal separation 4 pin mini DIN
Luminance signal: 1.0 Vp-p (75 ), Chrominance signal: 0.286 Vp-p (75 )
SDI input terminal 1 system (HD-SDI/SDI) BNC type
SDI output terminal 1 system (HD-SDI/SDI) BNC type
DVI-D input terminal Single link/2 system, DVI 1 supports HDCP DVI-D terminal
DVI-D output terminal Single link/1 system, outputs DVI 2 DVI-D terminal
RGB/YP
BPR input terminal
Y/G (BNC type) : with sync 1.0 Vp-p (75 )
P
B/PR (BNC type) : 0.7 Vp-p (75 )
R/B (BNC type) : 0.7 Vp-p (75 )
SYNC (BNC type) : 0.3 Vp-p – 4.0 Vp-p (75 )
RGB/YPBPR output terminal
Y/G (BNC type) : with sync 1.0 Vp-p (75 )
P
B/PR (BNC type) : 0.7 Vp-p (75 )
R/B (BNC type) : 0.7 Vp-p (75 )
SYNC (BNC type) : 0.3 Vp-p – 4.0 Vp-p (75 )
HD15 input terminal
R/G/B : 0.7 Vp-p (75 )
HD/VD : TTL (high impedance)
(mini D-sub15 pin)
RS-232C terminal External control terminal (D-sub 9 pin), RS-232C compliant
GPI input terminal
External control terminal (D-sub 9 pin)
Not set : open
Set : GND level (level operation only for Tally, edge operation in other cases)
DC output terminal DC5V 1A
Dimensions (W × H × D) 643 mm
(
25.3
)
× 396 mm
(
15.6
)
× 87 mm
(
3.4
)
Weight (Mass)
(Main unit)
Approx. 7.7 kg (17.0 lbs.)
Storage and transport
conditions
Ambient temperature: -20 °C – 60 °C (-4 °F – 140 °F)
Relative humidity: 10 % – 85 %
Atmospheric pressure: 700 hPa – 1060 hPa
Operating conditions
Ambient temperature: 5 °C – 35 °C (41 °F – 95 °F)
Recommended operating temperature: 20 °C – 30 °C (68 °F – 86 °F)
Relative humidity: 30 % – 85 %
Atmospheric pressure: 700 hPa – 1060 hPa
Water drip-proof IPX2
AC IN AC 100 V – 240 V 50 Hz/60 Hz – 1.2 A
DC OUT DC 24 V 4.16 A
Dimensions (W × H × D) 160 mm
(
6.3
)
× 37 mm
(
1.5
)
× 64 mm
(
2.5
)
Weight (Mass) Approx. 0.7 kg (1.5 lbs.)
Storage and transport
conditions
Ambient temperature: -20 °C – 60 °C (-4 °F – 140 °F)
Relative humidity: 10 % – 85 %
Atmospheric pressure: 700 hPa – 1060 hPa
Operating conditions
Ambient temperature: 5 °C – 35 °C (41 °F – 95 °F)
Recommended operating temperature: 20 °C – 30 °C (68 °F – 86 °F)
Relative humidity: 30 % – 85 %
Atmospheric pressure: 700 hPa – 1060 hPa
Protection class against
electric shock
Class I
