Preventative Maintenance Inspection Form
DFU-0276-4r0_fmt_en-US PM – 2/8
Real Panel of Console
Number
Rear Panel Elements
1
Supply main input Plug
2
Equipotential Bonding Pin with Stamped Equipotential Bonding Symbol
3
Address Label
4
Fan
5
USB port (For use ONLY by Service technicians)
6
Serial ports for Arthrex integration (to only be connected to IEC 60601-1 approved
equipment)
7
Serial number label
8
Model number label
9
Fuse holder for the Power Entry Module
10
Fuse label
