Preventative Maintenance Inspection Form
DFU-0276-4r0_fmt_en-US PM – 5/8
Additional Screen Information
Initials Action
Present/Not
Present
Make sure you are able to see the intelligent device recognition symbol [6]
Make sure you are able to see the footswitch symbol if a footswitch is
connected to the RF device. [7]
Make sure you are able to see the time burst symbol if time burst is active [8].
Make sure the display shows the name of the RF probe being used [9].
Function Check:
Use an Electrosurgical Analyzer to perform the following tests. To perform the function check, an
Apollo
RF
Service probe (AR-9899-T) can be utilized to simplify the process.
First, insert the red and black output connectors of the Apollo
RF
Service probe (AR-9899-T) into the red
and black variable load bank connections of the electrosurgical analyzer. Next, plug the Apollo
RF
Service probe (AR-9899-T) connector into the Synergy
RF
console (AR-9800). The Apollo
RF
Service probe
contains ablate and coagulate buttons to initiate those functions during the test.
Model Number: __________________________ Serial number: _____________________
Calibration Date: __________________________
Measurement
Measured Value
Limit / Test Level
Pass/Fail
Ablation, Setting 1 @ 300 Ohms
38 Watts +/- 20%
Ablation, Setting 5 @ 300 Ohms
143 Watts +/- 20%
Ablation, Setting 9 @ 300 Ohms
332 Watts +/- 20%
Coag, Setting 1 @ 50 Ohms
61 Watts +/- 20%
Coag, Setting 2 @ 50 Ohms
127 Watts +/- 20%
