1.5.5. USB Audio mapping
AudioFuse Studio displays differing numbers of input and output channels in your music
software depending on your selected sampling rate.
Sampling Rate Inputs Outputs
44.1 / 48 kHz 20 18
88.2 / 96 kHz 18 18
176.4 / 192 kHz 10 10
The tables below contain detailed information about inputs and outputs at each sampling
rate.
1.5.5.1. Audio Mapping at 44.1 / 48 kHz sampling rates:
Input Computer Input (REC) Computer Output (Playback)
1 Input Channel 1 Main Left
2 Input Channel 2 Main Right
3 Input Channel 3 Cue 1 Left
4 Input Channel 4 Cue 1 Right
5 Line Input 5 / Phono (Input 5) Cue 2 Left
6 Line Input 6 / Phono (Input 6) Cue 2 Right
7 Line Input 7 Aux Out Left
8 Line Input 8 / Talkback Aux Out Right
9 S/PDIF Left S/PDIF Left
10 S/PDIF Right S/PDIF Right
11 ADAT 1 ADAT 1
12 ADAT 2 ADAT 2
13 ADAT 3 ADAT 3
14 ADAT 4 ADAT 4
15 ADAT 5 ADAT 5
16 ADAT 6 ADAT 6
17 ADAT 7 ADAT 7
18 ADAT 8 ADAT 8
19 Loopback Left -
20 Loopback Right -
Arturia - User Manual AudioFuse Studio - AudioFuse Studio 31
