1.6. Specifications
• 18 inputs, 20 outputs channels
• 4 mic/instrument/line preamps with DiscretePRO® technology
• 4 additional line inputs, with inputs 5-6 commutable to Phono
• 4 analog inserts on channel 1-4
• Bluetooth stereo audio receiver supporting aptX© and AAC©
• 2 pairs of speaker analog outputs on balanced TRS Jack
• 2 independent stereo headphones outputs, on both 6.35 and 3.5mm TRS.
• 2 independent analog line outputs with reamp capability (instrument impedance
output)
• Complete monitoring section with individual level control for speakers and
phones
• Direct monitoring ultra-low latency internal mixers
• 8 digital ADAT inputs/outputs up to 96kHz
• S/PDIF inputs/outputs or Word clock input, output/thru on Cinch RCA
• Integrated Talkback feature with a dedicated built-in microphone
• MIDI In & Out
• 3-port USB hub (with two 1A ports for rapid charging)
• DiscretePRO® Individual audio performance certificate delivered with each unit.
• 24-bit latest generation AD/DA converters at up to 192kHz sampling rate.
• USB-C interface compatible with PC & Mac, fully USB 2.0 compatible
• Comes with AudioFuse Creative Suite
• Robust metal desktop chassis
Line Inputs
Input Impedance 20kΩ (symmetric), 10kΩ (asymmetric)
Maximum Input Level +24dBu
Gain Range 45dB typical
Pad Mode -20dB
Frequency Response 20Hz/20kHz +/-0.01dB typical
Dynamic Range 119dB (A-weighted)
THD+N -112dB (A-weighted)
Instrument Inputs
Input Impedance 1.1MΩ (asymmetric)
Maximum Input Level +18dBu
Gain Range 45dB typical
Pad Mode -20dB
Frequency Response 20Hz/20kHz +/-0.01dB typical
Dynamic Range 119dB (A-weighted)
THD+N -112dB (A-weighted)
Arturia - User Manual AudioFuse Studio - AudioFuse Studio 35
