Line Aux Inputs
Input Impedance 20kΩ (symmetric), 10kΩ (asymmetric)
Maximum Input Level +24dBu
Pad Mode -20dB
Frequency Response 20Hz/20kHz +/-0.02dB typical
Dynamic Range 120dB (A-weighted)
THD+N -108dB (A-weighted)
Microphone Preamps
Input impedance 3.4kΩ
Maximum input level +11dBu
Gain range 71dB typical
Boost mode +10dB
Pad mode -20dB
Frequency response 20Hz to 20kHz +/-0.09dB
Equivalent Input Noise (EIN) -129dB typical (un-weighted)
THD+N @ 1kHz -107dB (A-weighted)
Dynamic range 118dB (A-weighted)
Input Inserts
Output Impedance 240Ω balanced, 120Ω unbalanced
Input Impedance 20kΩ (balanced), 10kΩ (unbalanced)
Aux / Line / Speaker Outputs
Output Impedance 240Ω balanced, 120Ω unbalanced
Maximum Output Level +24dBu
Dynamic Range 121dB (A-weighted)
THD+N -108dB (A-weighted)
Frequency response 20-20kHz +/-0.07dB
36 Arturia - User Manual AudioFuse Studio - AudioFuse Studio
