Asada BEAVER 50 - １－３）Die-Head; ２） Specifications

1-3) Die-Head
• The diagram illustrates main parts of Die Head. Before changing the thread size, change Dies
and position of Selector Block．
(1/2"－2"Manual) (1/2"－2")
(1/2”－2”AT)
2) Specifications
* Specifications are subject to change without prior notice.
* Voltage made to order.
⑤
⑫
⑬
⑭
⑮
9
Cutting capability
BSPT/NPT 1／4”～2”（8A～50A），Bolt 3／8”～2”
Speed
40min
‐
1
(rpm) No load
Motor
Single phase Universal Motor,750W
Frequency
50／60Hz
Weight
44kｇ
Dimensions
535×430×340mm
（L）X（W）X（H）
②
③
①
④
⑤
⑥
⑧
⑩
⑪
①
②
②
④
⑤
⑦
⑪
⑨
⑨ Set Pin
⑩ Adjust Screw
⑪ Locking Lever
⑫ Open Close Lever
⑬ Link
⑭ Scale Plate
⑮ Die Nut
① T－Handle
② Selector Pin（silver）
③ Selector Pin（black）
④ Selector Block
⑤ Cam Plate
⑥ Profile Body
⑦ Set Block
⑧ Profile Pin
