2) Adjustment of Parts
2-1) Adjustment of Amount of Discharging Thread Oil
(1) Ensure the oil is filled into the tank up to the Strainer wire netting.
(2) If the amount of threading oil discharged from the Die-Head is not appropriate, adjust the
discharging amount with the Oil Adjust Screw.
(3) Loosen the lock nut of the Oil Adjust Screw.
(4) Turning the Oil Adjust Screw clockwise increases the amount of oil and counterclockwise turn
decreases the amount of oil.（fig.48）
(5) Tighten the lock nut after adjustment.
30
Less
More
Lock Nut
〈48〉
