INSTALLATION GUIDE
Room Controller 4 (NIRC4-xMN) LAN Connection (T-568B)
Figure 20. - LAN ferrite clamp example
Be aware that the ferrite clamp will not fit in between the base and the NIRC4 circuit board.
Therefore, the use of a backbox situated behind the base is required.
TD 93351EN / 21 March 2022 / Ver. B 19
