Part names and functions
①
Top control and Indicators
②
Zoom ring
③
Lamp cover
④
Filter
⑤
Remote control receiver
⑥
Projector lens
⑦
Air intake vent
⑧
Focus ring
⑨
AC cord connector
⑩
Terminals
⑪
Anti-thief slot
⑫
Speaker
⑬
Adjustable foot
⑭
Exhaust vent
⑨
⑬
⑫
⑭
⑥
①
② ③
④
⑤
⑦
⑧
⑩ ⑪
Caution
Hot air is exhausted from the exhaust vent. Do
not put heat-sensitive objects near this side.
