TABLE OF CONTENTS
3
Front door 53
Removing the front door 53
Installing the front door 53
Changing the hinge pin 53
Changing the hinge socket 54
Changing the door magnet/escutcheon
plate 54
Changing the handle 54
Changing the inner door 55
Changing the outer door seal 55
Changing the inner door seal 55
Changing/cleaning the filter holder 56
Changing the door switch 56
Changing the door switch pin 57
Front panel 58
Removing front panel 58
Installing front panel 58
Changing the fixing clip for the bottom
cover (female) 59
Changing the fixing clip for the bottom
cover (male) 59
Panel 60
Removing the panel 60
Installing the panel 60
Changing the panel handle 61
Changing the indication lamp/symbol
lens 61
Changing the main power button 62
Changing the push-button switches 63
Changing the DCU panel board and the
push-buttons 63
Electronic control unit 64
Changing the electronic control unit 64
Installing electronic control unit with its
holder 65
Condenser housing (TDC44) 66
Removing the condenser housing 66
Installing the condenser housing 66
Changing the condensed water pump 66
Changing the microswitch for the conden-
sed water pump 67
Changing the foam rubber seal 67
Changing the float 68
Water tank housing (TDC44) 69
Removing water tank housing 69
Installing water tank housing 69
Changing the water tank handle 69
Side panels 70
Changing the side panels 70
Bottom 71
Changing the bottom 71
Front rail 71
Changing the front rail 71
Program and options 72
Programs 72
Drying time 72
Change settings 73
Language 73
Locking a programme 73
Child lock on button 73
Program overview 74
Tumble drying 75
Cleaning and maintenance 76
Cleaning the fluff filter 76
Emptying the condensed water tank
(TDC44) 76
Cleaning the outside of the machine 77
Cleaning the fan 77
Cleaning the condenser (TDC44) 78
Drying guide TDC33
Drying guide TDC44
Circuit diagram
