PANEL
Removing the panel
1. Remove the three screws at the rear edge and
lift off the top cover.
2. TDC44: Pull out the water tank.
3. TDC44: Unscrew the 2 screws that secure the
panel to the front rail.
4. TDC33: Unscrew the 2 screws securing the
front rail.
5. Remove the 4 snap fasteners at the bottom
edge by bending the clips apart with a screw-
driver with a 6.5 to 7 mm wide blade. Un-
hook the panel.
WARNING
Take care when bending the clips apart not to
damage the plastic snap fasteners in the panel.
Installing the panel
6. Hook on the top edge of the panel and snap
closed the 4 snap fasteners at the bottom edge.
IMPORTANT
Support the centre with a screwdriver as the pa-
nel is pressed into place.
7. Refit the removed parts.
